30M maximum run length <3SDCM LED flexible strip and can be powered from one end only with no loss in brightness.

12.8W/m and emitting 1,280lm/M when using the IP67 rated version, IP20 versions are higher when 4000K is selected.

48V DC supply feeding strings of 13 x SMD2835 LED chips. Each string is driven at the optimal mA’s to provide a stable colour output and to prolong the life due to the maintained constant current.

130 quantity of SMD2835 LED chips per meter provide an unbroken line of light when used in conjunction with an opal diffuser or set back in to a pelmet.

CRI>80 (>100 lumens per watt). Cutting distance is every 100mm.

Requires a suitable 48V power supply appropriate to the total wattage based on the run length. A safety factor of +10% should be used for non-dimming power supplies but a safety factor of +30% should be used for dimming power supplies to ensure dimming stability.

10mm PCB width for IP20 rated versions and 12mm sleeving width for IP67 rated versions.

3M high bond adhesive tape is installed on to the back of the LED PCB strip for ease of installation. Supplied with live feed connector.

Due to the delicate components used in this producte care should be taken when installing. Do not twist, bend or stretch the LED strip. Always carefully unwind large reels on a unspooling device.
